LAEC018-GN2

LG LED All-in-One

Key Feature

  • Pixel Pitch: 1.88 mm

  • Screen Size: 163” (Full HD)

  • Brightness: 500 nit (Max., after calibration)

  • Embedded System Controller

  • Built-in Speaker

  • Dedicated Accessories : Wall Mount, Dedicated Stand (Optional)


All-in-One LED Display with webOS

* All images in this page are for illustrative purposes only and may differ from the actual product.

* Stand accessories differ by models, and need to be purchased separately.

All-in-One

LED Screen with

Built-in Speaker

LG’s LED All-in-One LAEC series has two size of screens; 136- inch and a 163-inch. The LAEC series is offered as an all-in-one package including an embedded controller and built-in speaker. Eliminating the prejudice that LED displays are difficult and complex to install, it doesn't require controller connections or module configuration. After a simple installation process, all you need to do is to turn on the screen with a remote control like home TV.

High Performance

with webOS

Built-in Quad Core SoC (System on Chip) can execute several tasks at once for providing smooth content playback. Also, LG webOS Smart Platform enhances user convenience with intuitive GUI and provides to SI or/and developers simple app development tools* such as SDK (Software Development Kit), SCAP, sample applications.

* The webOS Signage Developer site (https://webossignage.developer.lge.com) provides SDK tools and documentation for creating apps on LG Digital Signage. This is only open to partners.

Easy Installation

The installation process of the All-in-One Smart series is very simple. After securing cabinets (two for LAEC015, three for LAEC018), attach each LED display module to them. Lastly, plug in the power cable. This simple installation saves time and labor, thereby making users handle the LED screen with ease.

* Fixing screws or installing wall mount / accessories is needed additionally.

* The image is illustrated as an example of LAEC015 model.

Tech Spec

  • Pixel Configuration Single SMD

    Pixel Pitch (mm) 1.88

    Module Dimensions (W x H, mm) 300 × 168.75

    Screen Resolution (WxH) 1,920 x 1,080

    Screen Dimension (W x H x D,mm) 3,604 × 2,029 × 45.5 (Thickest 81)

    Screen Weight (kg) 190

    No. of Modules per Screen (W x H) 12 × 12 (Total 144)

    Screen Surface Area (㎡) 7.29

    Physical Pixel Density (pixels/m²) 284,444

    Flatness of Cabinet ±0.2 mm

    Cabinet Material Aluminum

    Service Access Front

  • Max Brightness (After Calibration, nit) 500

    Color Temperature (K) 3,200 - 9,300

    Visual Viewing Angle (Horizontal/Vertical) 160 / 160

    Brightness Uniformity 98%

    Color Uniformity ±0.015Cx,Cy

    Contrast Ratio 3000 : 1

    Processing Depth (bit) 16 (HDR10, HDR10 Pro)

  • Power Consumption (W/Screen, Max.) 2,200

    Power Consumption (W/Screen, Avg.) 880

    Power Consumption (W/m², Max.) 302

    Power Consumption (BTU/h/Screen, Max.) 7,506

    Power Consumption (BTU/h/Screen, Avg.) 3,004

    Power Consumption (BTU/h/㎡, Max.) 1,030

    Power Supply (V) 100 to 240

    Frame Rate (Hz) 50 / 60

    Refresh Rate (Hz) 3,000

  • Lifetime (Hours to Half Brightness) 100,000

    Operating Temperature (°C) 0℃ to +40℃

    Operating Humidity 10-90% RH

    IP rating Front / Rear IP30 / IP20

  • Speaker Built-in (9W + 9W)

  • Certification CE, FCC, ETL, CB

  • Environment RoHS, REACH

  • Controller Embedded
