65UL3J-E
UHD Standard Signage
Key Feature
Brightness(Typ.) : 400 nits
Resolution : ULTRA HD (3,840 x 2,160)
EPEAT Registered
webOS-based High Performance
Compatible with LG's One:Quick Share
Compatible with AV Control Systems
LG webOS UHD Signage
* All images in this web page are for illustrative purposes only.
LG’s Wireless Screen Sharing Solution, LG One:Quick Share
LG One:Quick Share is a wireless screen sharing solution available through the UL3J series, USB transmission unit, and its app. You can simply share personal PC screen to the display with it's USB dongle button and embedded Wi-Fi*, and can adjust the basic setting values (volume, picture mode, auto bright, etc.) of the connected display without a remote control. Also, the Office Meeting Mode** helps you to display the agenda, note before the meeting starts.
* Users need to set up Soft AP enabled at Network Menu of the Signage.
** Users can enable Office Meeting Mode at EZ Setting Menu of the Signage.
*** LG One:Quick Share needs to be purchased separately.
Remote Monitoring and Control
This web-based monitoring solution is user-friendly and allows the user to be at ease. It enables the user to have full access anywhere at anytime from their mobile phone & PC under network-accessible environment while having access to both current and past data. It allows the user to monitor the unit, make adjustments and control the unit remotely in real time.
Compatible with AV Control Systems
The UL3J series supports Crestron Connected®* for high compatibility with professional AV controls to achieve seamless integration and automated control**, boosting business management efficiency.
* Initial setting from display is required for Crestron Connected® compatibility.
** Network based control
Compatible with Video Conference System
For effective visual meeting, the UL3J series supports its compatibility with Cisco solutions that offers powerful and integrated control* for a smarter video conference.
* Using an HDMI cable connection (HDMI cable is optional)
Wireless Access Point
UL3J series operates as a virtual router which can be an wireless access point for mobile devices.
Superb Picture Quality with Ultra HD Resolution
With the resolution of UHD, it makes the color and details of the contents vivid and realistic. In addition, the wide viewing angle provides clear contents.
Tech Spec
-
Screen Size 65”
Panel Technology IPS
Native Resolution 3,840 X 2,160 (UHD)
Brightness (Typ.) 400 nit
Contrast Ratio 1,200 : 1
Dynamic CR 1,000,000 : 1
Color gamut DCI 80 %
Viewing Angle (H x V) 178 × 178
Color Depth 1.07Billon colors(8bit + FRC)
Response Time 8ms (G to G)
Surface Treatment 1%
Operation Hours (Hours / Days) 16 / 7
Portrait / Landscape Yes / Yes
-
Bezel Color Ashed Blue
Bezel Width Off : 6.8/6.8/6.8/18.4
On : 12.8/12.8/12.8/19.9
Weight (Head) 21.5 kg
Monitor Dimensions (W × H × D) 1,454 x 838 x 57.7 mm
Carton Dimensions (W × H × D) 1,600 x 970 x 172 mm (Box outer size)
Handle No
VESA™ Standard Mount Interface 300 × 300 mm
-
Operation Temperature 0 °C to 40 °C (Portrait Scene : 0 °C to 35 °C)
Operation Humidity 10 % to 80 %
-
Power Supply AC 100-240V~, 50/60Hz
Power Type Built-In Power
-
Typ./Max. 130 W / 187 W
BTU (British Thermal Unit) 443.578BTU/Hr(Typ.), 638.071BTU/Hr(Max.)
-
Safety CB / NRTL
EMC FCC Class "A" / CE
ErP Yes (NewErp)
-
SuperSign CMS Yes
SuperSign Control / Control+ Yes
SuperSign WB Yes
SuperSign Media Editor Yes
LG ConnectedCare Yes
-
Input HDMI (3, HDCP 2.2 / 1.4), USB 2.0 Type A (2)
Output Audio
External Control RS232C In / Out (4 Pin Phone Jack), RJ45 (LAN) In
-
Speaker Yes
-
Basic
Remote Controller(include battery 2ea), Power Cord, Regulation Book, Phone to D-Sub9 Gender, Cable Holder
