BF40QS
ProBeam Laser WUXGA with 4,000 ANSI Lumens Brightness
Key Feature
WUXGA Laser
2.3 Mega Pixels (1920x1200)
4,000 ANSI Lumens
webOS
Lens shift H ±20%, V ±50% & Zoom x 1.6
4 Corner Keystone
Designed for Business Innovation
Display
WUXGA (1920 x 1200) Laser
4,000 ANSI Lumens
Smart
Wireless Connection
webOS
Usability
Lens shift H ±20%, V ±50%
Zoom x 1.6
4,000 ANSI Lumens
Maximize Power of Presentation
4,000 ANSI lumens of brightness delivers accuracy and clarity, even in brightly lit conference rooms without loss of picture quality, magnifying productivity of business meetings.
Scalable & Adaptive Projector
Fits to Any Business
Enterprise : Efficiency & Productivity
This corporate-quality projector is designed for business meeting, conferences and collaboration. It allows users to boost work efficiency and productivity.
Flexible and Easy Installation
With Lens Shift (H ±20%, V ±50%) & Zoom x1.6 functionality, the user can install the device anywhere and set the screen to the exact size and location.
4 Corner Keystone
Adjust the screen from four different points to achieve accurate proportions with horizontal and vertical alignment.
The Smallest WUXGA 4,000 ANSI Projector
Sufficiently Compact Size
LG BF40QS, has not only 16.7 liter compact body but also WUXGA (1920x1200) resolution and 4,000 ANSI lumens brightness, perfectly matches any business space.
webOS + Screen Share + Bluetooth
Smart Wireless Connection
For smart communication, you can share the screen and sound conveniently with wireless mirroring (screen share) and Bluetooth pairing. With webOS, you can connect to internet and explore the reference using Wi-Fi network.
-
PROJECTION SYSTEM
Projection System DLP
NATIVE RESOLUTION
Native Resolution WUXGA (1920 x 1200)
BRIGHTNESS(ANSI LUMEN)
Brightness (ANSI Lumen) 4000
CONTRAST RATIO
Contrast Ratio 3,000,000:1 ↑
NOISE
Energy Saving Min. (Bright) 29Energy Saving Med. 27
Energy Saving Max. (Eco) 26
UNIFORMITY
Uniformity (JBMMA 9 Point) 85%
PROJECTION LENS
Focus (Auto / Manual) ManualZoom 1.6x
PROJECTION IMAGE
Screen Size 40" ~ 300"Standard (lens to wall) Wide 2800 /Tele 4500 (100 inch)
Throw Ratio 1.30 - 2.08
LENS SHIFT
Lens Shift Yes ( Horiz ± 20% / Vert ± 50% )
LIGHT SOURCE
Type Laser (LD + P/W)Life Hours 20,000 Hrs
ASPECT RATIO
Aspect Ratio Control 16:9/16:10/Original/4:3/Vertical Zoom/All-Direction Zoom
SOUND
Output 10W (5W+5W)
SIZE
Net Size (mm) (W x D x H) 370 x 290 x 155.7
370 x 290 x 143.7 (Without Leg)
WEIGHT
Net Weight (kg or g) 1
POWER
Power Consumption (Max.) 245WStand-by Power 0.5W↓
Power Supply 100V – 240V @ 50~60 Hz (PSU Built-in)
TEMPERATURE
Operation Temperature 0 ~ 40℃
INPUT SIGNAL COMPATIBILITY
Digital(HDMI) Up to 4K (4096x2160) (60Hz, 50Hz, 24Hz)
INPUT/OUTPUT TERMINALS
Audio Out YesRS-232C Yes
IP control YesRJ45 1
HDMI 2USB Type-A 2 (USB2.0)
FEATURES
Platform (OS, UI) webOS 4.5Internet Browser Yes
Screen Share (Wireless Mirroring with MiraCast supporting device) YesWireless Contents Share (with Android, iOS) Yes (Android Only)
Contents Sharing (with DLNA supporting device) YesBluetooth Sound out Yes
Bluetooth AV Sync Control YesLG Sound Sync(with Sound Bar) Yes
HDMI ARC(Audio Return Channel) YesPlug & Play(RGB/DVI/HDMI Auto Source Detection) Yes
USB Host (Movie, Music, Photo) YesFile(Office) Viewer Yes
Setting Guide Yes (Bean Bird)
HID (Keyboard/Mouse/GamePad Connection Thru USB) Yes
HDR YesHDR Effect Yes
Digital Keystone Correction 4 coner Keystone (H/V)Image Flip Yes (Horizontal/Vertical)
Black Level Control Yes
Noise Reduction Yes
Quick(Instant) Power on/off Yes (on 12 Sec off 2 Sec)
Self Diagnosis Yes
DESIGN
Cabinet Color Top/Bottom - White
Front/Rear - Light Grey
Local Key Joystick
Kensington Lock Yes
Leg-Stand Yes (4 Leg)
Ceiling mount hole (for bracket) Yes
