55VL5F-A

VL5F Series

Key Feature

  • Brightness(Typ.) : 500 cd/m²

  • Bezel : 2.25 mm (T/L), 1.25 mm (B/R)

  • Depth : 93.1 mm

  • Interface : HDMI (2)/ DP/ DVI-D/ USB/ RS232C/ RJ45/ Audio/ IR


Incredible Immersion with Ultra-Narrow Bezel

The VL5F series provides all-encompassing screen immersion thanks to its ultra-narrow 3.5 mm bezel-to-bezel, while its outstanding IPS panel delivers a clear image from any angle. With its extremely attractive and highly functional design, it can be used to deliver advertising and information in a variety of business environments.

55VL5F-A

Achieving Incredible Immersion

Seamless Large Screens with Ultra-Narrow Bezel

The ultra-narrow bezel creates a visually stunning digital wall to effectively deliver dynamic content and immerse the viewers. The large screen it generates is enough to captivate the attention of passersby.

Achieving Incredible Immersion

Image Gap Reduction

The VL5F series includes an image improvement algorithm that can reduce image gaps among tiled displays when playing back videos. Objects located on the bezel boundaries are adjusted for a seamless viewing experience.

Dynamic Picture Quality

Vivid and Dynamic Picture Quality

Higher Viewing Angle

Large screens are usually positioned higher than human-eye level, making uniform picture quality essential for video walls. The viewing angle of the VL5F series is high enough to display vivid colors throughout the screen with no distortion.

User Convenience

Easy Color Adjustment

Depending on the content, the color temperature of the display can be easily adjusted in increments of 100K using a remote control.

Easy Color Adjustment

Tech Spec

  • Screen Size 55"

    Panel Technology IPS

    Aspect Ratio 16 : 9

    Brightness (Typ., cd/m²) 500

    Contrast Ratio 1,200:1

    Dynamic CR 500,000 : 1 (The luminosity ratio of Full Black/Full White color on video input condition.)

    Viewing Angle (H x V) 178 x 178

    Response Time 8 ms (G to G)

    Surface Treatment 3%

    Life Time (Typ.) 60,000 Hrs

    Operation Hours 24 Hrs

    Orientation Landscape & Portrait

  • Bezel Color Black

    Bezel Width 2.25 mm (T/L) / 1.25 mm(B/R)

    Weight (Head) 20.3 kg

    Packed Weight 33 kg

    Monitor Dimensions (W × H × D) 1,213.4 x 684.2 x 93.1 mm

    Carton Dimensions (W × H × D) 1,353 x 980 x 263mm

    Handle Yes

    VESA™ Standard Mount Interface 600 x 400 mm

  • Operation Temperature 0°C to 40°C

    Operation Humidity 10 % to 80 %

  • Power Supply 100-240V~, 50/60Hz

    Power Type Built-In Power

  • Safety CB / NRTL

    EMC FCC Class "A" / CE / KC

    ErP Yes (EU Only)

  • Typ./Max. 130 W / 150 W

    Smart Energy Saving 62 W

  • Content Management Software SuperSign CMS

    Control and Monitoring Software SuperSign Control/Control+

  • Input HDMI(2), DP, DVI-D, Audio, USB

    Output DP, Audio

    External Control RS232C In/out, RJ45(LAN) In, IR In

  • OPS type compatible No

  • IP Rating IP5X tested

  • Basic

    Remote Controller, Power Cord, RS232C Cable, DP Cable, IR Receiver, Guide Bracket, Screws, Manual

    Optional

    Wall Mount (Landscape: WM-L640V, Portrait: WM-P640V)
