55EW5TK-A

Transparent OLED Touch Signage

Key Feature

  • Brightness(Typ.) : 150 / 400 nit (APL 100% / 25%, Without Glass)

  • Bezel : 7.9 mm (T/B/L), 144.5 mm (B)

1649639090693_76661 - Copy.jpg
1649639100475_36147 - Copy.jpg

See Beyond, LG Transparent OLED

Touch Signage

* All images in this web page are for illustrative purposes only.

Imagination becomes reality

A New Level of See-through View

LG Transparent OLED Signage illuminates spaces that once were hidden away behind the display, completely harmonizing with its surroundings.

Boasting vivid and clear colors with high transparency, this display provides visual enhancements to objects placed behind it, giving viewers an impressive "wow" factor.

Not only that, it can respond according to viewers’ touch, which has great potential for various applications where customer interactions are required.

Accurate and Vivid Colors

Featuring self-lighting pixels, the display maintains vivid colors and high contrast ratio even when the display becomes transparent. It brings content to life from wide viewing angles, and the content blends into its surroundings seamlessly and naturally.

Tech Spec

  • Screen Size 55”

    Panel Technology OLED

    Native Resolution 1,920 X 1,080 (FHD)

    Brightness 150 / 400 nit (APL 100% / 25%, Without Glass)

    Contrast Ratio 150,000 : 1

    Color gamut BT709 120%

    Viewing Angle (H x V) 178 × 178

    Color Depth 1.07 Billon Colors (10 bit (R))

    Response Time 1 ms (G to G), 8 ms (MPRT)

    Surface Treatment (Haze) Hard Coating (2 H)

    Operation Hours (Hours / Days) 18 / 7 (Moving Content Only)

    Portrait / Landscape Yes / Yes

  • Bezel Color Matt Silver

    Bezel Width 7.9 / 7.9 / 7.9 / 144.5 mm (T/R/L/B)

    Weight (Head) 12.9 kg (Head)

    3.4 kg (Signage Box)

    Monitor Dimensions (W × H × D) 1,225.5 × 832.9 × 7.4 mm (Head)

    782.8 × 238.4 × 34.7 mm (Signage Box)

  • Key Feature Internal Memory (16 GB), Sensor (Temperature Sensor), webOS 4.0, Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail Over, Video Tag (4), Rotation (Screen Rotation), Gapless Playback, Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, 3rd Party Compatibility (Crestron Connected® (Network based control.)), Power (PM Mode, Wake on LAN), HDMI-CEC (Compatibility may differ by equipment.), SI Server Setting, Pro:Idiom

  • Operation Temperature 0 to 40

    Operation Humidity 10%-80%

  • Power Supply AC 100-240 V~, 50/60 Hz

    Power Type Built-in Power

  • Typ./Max. 84W (IEC 62087) / 300 W (TBD)

    BTU (British Thermal Unit) TBD

  • Safety IEC 60950-1 / EN 60950-1 / UL 60950-1

    EMC FCC Class "A" / CE / KC

    ErP Yes

  • SuperSign CMS Yes

    SuperSign Control / Control+ Yes

    SuperSign Media Editor Yes

    LG ConnectedCare Yes * The availability can differ by region.

  • Input HDMI (HDCP 1.4), DP (HDCP 1.3), RS-232C In, RJ45 (LAN), IR In (External IR Receiver), USB 2.0 Type A, USB 2.0 Type A (Touch Control Board Only)

    Output DP Out, Audio Out, Touch USB (USB 2.0 Type B), RS-232C Out (w / IR Out), RJ45 (LAN)

  • OSD English, French, German, Spanish, Italian, Korean, Chinese (Simplified), Chinese (Original), Portugues (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues (Europe), Dutch, Czech, Greek, Arabic

  • Basic Remote Controller, Power Cord, QSG, IR Receiver, Regulation Book, Phone to RS-232C Gender, MCX / Harness Cables (3,000 mm × 4 ea / 3,000 mm × 2 ea for Connection between Panel and Signage Box), HDMI Cable (3 M) Micro to A type USB Cable (3 M (TBD) for Connection between Touch and Signage box), A to B Type USB Cable (Touch Out), Screw (M4 × L22, 12 ea / M4 Nut 12 ea / M3 × L5.5, 8 ea / M3 × L3.5, 20 ea), Shield Cover Assy’, Rubber Damper 4 ea, Touch Cable Holder 2 ea, MCX Cable Holder 4 ea

  • Available Object Size for Touch Ø 12 mm ↑

    Response Time 120 ms ↓

    Accuracy 3.5 mm

    Interface USB 2.0

    Protection Glass Thickness 3.0 T (Anti-Glare / Anti-Finger Print)

    Protection Glass Transmission 84 % (Typ.)

    Operating System Support Windows 8.1, Windows 10

    Multi Touch Point Max. 10 Points
