55EJ5K

Flat OLED Signage

Key Feature

  • Brightness(Typ.): 150/400 nit (APL 100% / 25%)

  • Bezel : 5.3 mm (T/B/L), 11.0 mm (B)

  • Interface : HDMI/DP/USB(2)/ RS232C/ RJ45/ Audio/ IR


Artistic Space beyond Display,

LG Wallpaper OLED Signage

* All images in this web page are for illustrative purposes only.

Absolute Black

Equipped with over 8 million self-lighting pixels operating individually, LG OLED Signage reproduces absolute blacks with no light bleed and offers infinite contrast.

Rich Color

LG OLED Signage provides richness in all colors, bringing colors to life with great accuracy and vividness.

N×N Expandable Screen Size

By tiling up displays horizontally and vertically, the screen size can be as large as users want. Expansive, large screens are more effective at moving viewers by providing an incredibly immersive viewing experience.

LAN Daisy Chain Management

A LAN daisy chain is supported, allowing you to execute commands to control and monitor the displays and even update their firmware.

Splendid Design

LG’s OLED technology unlocks the new worlds of design flexibility with unbelievably lightweight and slim display. The advantages the OLED display brings are countless from the easier installation to a sleek look.

Tech Spec

  • Screen Size 55”

    Panel Technology OLED

    Native Resolution 1,920 X 1,080 (FHD)

    Brightness 150 / 400 nit (APL 100% / 25%)

    Contrast Ratio 150,000 : 1

    Color gamut BT709 120%

    Viewing Angle (H x V) 178 × 178

    Color Depth 1.07 Billon Colors (10 bit (R))

    Response Time 1 ms (G to G), 8 ms (MPRT)

    Surface Treatment (Haze) Hard Coating (2 H), Reflectance Typ. 1.2%

    Operation Hours (Hours / Days) 18 / 7 (Moving Content Only)

    Portrait / Landscape Yes / Yes

  • Bezel Color Black

    Bezel Width 0.9 mm (Even Bezel) (Off Bezel)

    5.3 / 5.3 / 5.3 / 11.0 mm (T/R/L/B) (On Bezel)

    Weight (Head) 6.5 kg (Head)

    3.4 kg (Signage Box)

    Monitor Dimensions (W × H × D) 1,220.3 × 696.8 × 4.9 mm (Head)

    782.8 × 238.4 × 34.7 mm (Signage Box)

  • Key Feature Internal Memory (16 GB), Sensor (Temperature Sensor), webOS 4.0, Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail Over, Sync Mode (RS-232C Sync, Local Network Sync), Video Tag (4), Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Tile Mode Setting, Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, 3rd Party Compatibility (Crestron Connected® (Network based control.)), Power (PM Mode, Wake on LAN), HDMI-CEC (Compatibility may differ by equipment.), SI Server Setting, Pro:Idiom

  • Operation Temperature 0 to 40

    Operation Humidity 10%-80%

  • Power Supply AC 100-240 V~, 50/60 Hz

    Power Type Built-in Power

  • Typ./Max. 116W (IEC 62087) / 318 W

    BTU (British Thermal Unit) 1,054 BTU/Hr (Typ.), 1,085 BTU/Hr (Max.)

  • Safety IEC 60950-1 / EN 60950-1 / UL 60950-1

    EMC FCC Class "A" / CE / KC

    ErP Yes

  • SuperSign CMS Yes

    SuperSign Control / Control+ Yes

    SuperSign WB Yes

    SuperSign Media Editor Yes

    LG ConnectedCare Yes * The availability can differ by region.

  • Input HDMI (HDCP 1.4), DP (HDCP 1.3), RS-232C In, RJ45 (LAN), IR In (External IR Receiver), USB 2.0 Type A (2)

    Output DP Out, Audio Out, RS-232C Out (w / IR Out), RJ45 (LAN)

  • OSD English, French, German, Spanish, Italian, Korean, Chinese (Simplified), Chinese (Original), Portugues (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues (Europe), Dutch, Czech, Greek, Arabic

  • Basic

    Remote Controller, Power Cord, QSG, IR Receiver, Regulation Book, Phone to RS-232C Gender, FFC Cables (1,600 mm × 4 ea for Connection between Panel and Signage Box), DP Cable (2 M), LAN Cable (1.5 M), RS-232 Cable (4P-4P, 1.5 M), LC Cable (VLC, 3 M), Wall Fixer (4 ea), Wall Fixer Install Guide, Install Guide Sheet (2 ea), Tape (10 ea for Cabling / 2 ea for Dust Proof), Screw (M4 × L25, 10 ea / M3 × L5.5, 8 ea)
