1/1.3" SENSOR
Capture every detail.
A larger 1/1.3" sensor with 2.4 μm equivalent pixel size offers 2.23 times the photosensitive area of Link 2, delivering stunning detail and dynamic range.
2.23×
Larger photosensitive sensor area relative to Link 2
2.4μm
Max. equivalent pixel size
EXCEPTIONAL LOW-LIGHT PERFORMANCE
The master of the night.
Clear, vibrant video in any condition, from dim home offices to bright studios. Advanced image processing ensures perfectly balanced visuals for better presentation.
TRUE-TO-LIFE HDR
Captures true-to-reality.
Dual Native ISO with HDR preserves bright highlights and deep shadows simultaneously, for a realistic, balanced image.
NATURAL BOKEH
Always in focus.
Intelligently recognizes people and adjusts depth of field in real time. Professional, cinematic, keeping you clear and sharp.
TRUE FOCUS
Always sharp, always ready.
Phase Detection Auto Focus (PDAF) locks on with speed and precision. Fast, reliable, crisp focus.
PROFESSIONAL AUDIO
Upgraded dual-mic system, engineered for clarity.
Features both a directional and omnidirectional mic for richer, broadcast-ready fidelity.
WHITEBOARD MODE
Clarity made simple.
Bring ideas to life in perfect detail. Wave your hand, and AI instantly detects your whiteboard and enhances it in real time, giving you a clear, distortion-free view. You can also toggle it anytime via the Controller.
DESKVIEW MODE
Your desk, perfectly displayed.
Tilt down to share your workspace in real time. Ideal for showing sketches, documents, or demos with total ease.
*For Insta360 Link 2C Pro, adjust the mount manually, then fine-tune the angle in Link Controller.
GESTURE CONTROL
Control, hands-free.
Stay focused on what you’re doing while Link 2 Pro follows your lead. Use gestures to switch modes, track, or zoom in or out.
PORTRAIT MODE
Perfectly vertical, instantly social.
Switch to native 4K 9:16 capture for flawless vertical video. Just rotate the camera and you’re social-ready in seconds—no cropping needed.
Specification
-
Video Resolution
Landscape: 4K@30/25/24fps 1080p@60/50/30/25/24fps 720p@60/50/30/25/24fps 360p@30/25/24fps Portrait: 4K@30/25/24fps 1080p@60/50/30/25/24fps 720p@60/50/30/25/24fps
Video Coding Format
H.264, MJPEG (4K and 1080p60fps Portrait mode do not support H.264)
Exposure Compensation
±3 EV
ISO
Dual Native ISO 100~3200
Shutter Speed
1/8000~1/30s
White Balance
2000~10000K
Aperture
F/1.9
35mm Equivalent Focal Length
24 mm
Fixed FOV
83.9º DFOV, 71.4º HFOV
Digital Zoom
Up to 4×
Autofocus
Supported (Focus distance: 12cm–∞)
HDR
Supported
Microphones
2
Noise Reduction
AI Noise-Canceling
Audio Modes
Standard, Wide, Focus, Original
Modes
AI Tracking, Smart Whiteboard, DeskView, Virtual Background
-
Gimbal
2-Axis
-
Button
1× Touch Key
Connectivity
USB-C Cable (USB 2.0) or USB-C to USB-A adapter
Power Consumption
5V/1A
Mounting Options
Magnetic Mount with 1/4" mounting point for external tripod
Dimensions (W × H × D)
71.3×58.9×38mm (2.8×2.3×1.5in)
Weight
Without Magnetic Mount: 102.5g (3.6oz) With Magnetic Mount: 167.5g (5.9oz)
Operating Temperature
32°F to 104°F (0°C to 40℃) *Tested in a lab environment.
Color
Graphite Black
-
CPU
i5-5 generation or later (advanced features require i5-10 generation or later)
RAM
8GB or above (advanced features require 16GB or above)
Link Controller
Windows: Windows 10 or later. Does not support ARM-based Windows. Mac: macOS 11.0 or later. Virtual Camera requires macOS 13.0 or later.
Background Blur & Background Replacer
Windows: Supports all NVIDIA GPUs. AMD GPUs may experience compatibility issues; please contact the Insta360 Customer Service team before purchasing. Verified AMD GPUs include Radeon (TM), RX Vega 10, 780M, RX 560, RX 6600 and RX 6750 GRE. Mac: macOS 13.0 or later.
Green Screen
Windows (NVIDIA GTX 1050 Ti & above): Up to 4K Windows (NVIDIA below 1050 Ti): Not supported Windows (Non-NVIDIA GPUs): Up to 4K macOS (Apple Silicon): Up to 4K macOS (Intel): Up to 1080p
Natural Bokeh
Windows: NVIDIA GTX 1080 or later, RTX 2060 or later GPUs. Does not support AMD GPUs. Resolution support (depends on GPU capability): Desktop GPUs: Compute capability 8.6 or higher: Supports 4K and below Compute capability below 7.5: Supports 1080p and below Laptop GPUs: Compute capability 8.9 or higher: Supports 4K and below Compute capability below 8.6: Supports 1080p and below For GPU specs, visit NVIDIA’s official page. Mac: M1 chip or later. Does not support Intel chips. *Insta360 Virtual Camera is automatically installed with Link Controller. Virtual Camera supports Smart Whiteboard Mode, Natural Bokeh, Background Blur, Background Replacer, Beautify and Makeup. Virtual Camera does not support 50fps or 60fps. 4K resolution for Beautify and Makeup is currently only supported on macOS (Apple M1 or later and Intel i5 or later).
